Volvo Ec380dL Pdf Excavator Service Repair Manual
$59.99
Volvo ec380dl Repair Manual
Volvo Ec380d L, Ec380d Nl Parts Catalogue Manual
What oil does a Volvo diesel take?
The type of oil that a Volvo diesel engine takes depends on the specific model and operating conditions. For most Volvo construction equipment, including excavators like the Volvo EC380DL, Volvo recommends using Volvo VDS (Volvo Drain Specifications) oils, which are formulated specifically for their engines.
Commonly Recommended Oil Types:
Volvo VDS-4.5 (or VDS-4) – Full Synthetic or Synthetic BlendFor modern, high-performance diesel engines, meeting emissions standards.
API CJ-4 or CK-4 Engine Oil (in the absence of VDS oils)These oils meet or exceed the requirements for heavy-duty diesel engines.
Viscosity:
SAE 15W-40 is the most commonly recommended viscosity for normal conditions.
SAE 10W-30 or 5W-40 may be recommended for colder climates.
Always consult your Volvo operator’s manual for the exact oil specifications tailored to your machine’s model and operational conditions.
Volvo Ec380d L Ec380dl Specfications
Volvo ec380dl Pdf Covers:
Safety
0 General
1 Standard Parts, Service
2 Engine with Mounting and Equipment
3 Elec. System, Warning System, Information System, Instruments
4 Power Transmission
5 Frame and Crawler Unit
6 Machinery House, Cab, Exterior Trim Parts Anywhere
7 Hydraulic System, Digging, Handling, Grading Equipment, Misc Equipment
Hydraulic and Electric schematics
Volvo Ec380d L Ec380dl Excavator Service Repair Manual
Specification
Engine
Make Volvo
Model D13H
Gross Power 293 hp 218.5 kw
Net Power 283 hp 211 kw
Power Measured @ 1700 rpm
Displacement 781 cu in 12.8 L
Torque Measured @ 1300 rpm
Max Torque 1165.3 lb ft 1580 Nm
Number of Cylinders 6
Aspiration Turbocharged and Intercooled
Operational
Operating Weight 84326.8 lb 38250 kg
Fuel Capacity 163.8 gal 620 L
Cooling System Fluid Capacity 15.9 gal 60 L
Hydrauilc System Fluid Capacity 132.1 gal 500 L
Engine Oil Capacity 11.1 gal 42 L
Operating Voltage 24 V
Alternator Supplied Amperage 80 amps
Hydraulic System Relief Valve Pressure 5120 psi 35301.1 kPa
Hydraulic Pump Flow Capacity 158.5 gal/min 600 L/min
Swing Mechanism
Swing Speed 10.2 rpm
Swing Torque 96257 lb ft 130507 Nm
Undercarriage
Number of Shoes per Side 50
Shoe Size 27.6 in 700 mm
Number of Carrier Rollers per Side 2
Number of Track Rollers per Side 9
Ground Pressure 8.5 psi 58.8 kPa
Max Travel Speed 3.3 mph 5.3 km/h
Drawbar Pull 62181 lb 276.6 kN
Track Gauge 9 ft in 2740 mm
Buckets
Reference Bucket Capacity 3.2 yd3 2.4 m3
Maximum Bucket Capacity 3.6 yd3 2.8 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 21’2″ (6450mm) boom / 8’6″ (2600mm) stick
Shipping Height of Unit 11.6 ft in 3530 mm
Shipping Length of Unit 37 ft in 11280 mm
Max Digging Depth 22.5 ft in 6850 mm
Max Reach Along Ground 33.9 ft in 10330 mm
Max Cutting Height 33.4 ft in 10170 mm
Max Loading Height 23.3 ft in 7090 mm
Max Vertical Wall Digging Depth 17.8 ft in 5430 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2 21’2″ (6450mm) Boom / 10’6″ (3200mm) Stick
Shipping Height of Unit 10.8 ft in 3280 mm
Shipping Length of Unit 35.9 ft in 10940 mm
Max Digging Depth 24.4 ft in 7450 mm
Max Reach Along Ground 35.6 ft in 10860 mm
Max Cutting Height 33.9 ft in 10340 mm
Max Loading Height 23.9 ft in 7280 mm
Max Vertical Wall Digging Depth 19.3 ft in 5870 mm
Boom/Stick Option (HEX) 3
Boom/Stick Option (HEX) 3 21’2″ (6450mm) Boom / 12’10” (3900mm) Stick
Shipping Height of Unit 11.4 ft in 3470 mm
Shipping Length of Unit 36.8 ft in 11220 mm
Max Digging Depth 26.7 ft in 8150 mm
Max Reach Along Ground 37.8 ft in 11520 mm
Max Cutting Height 34.8 ft in 10610 mm
Max Loading Height 24.8 ft in 7560 mm
Max Vertical Wall Digging Depth 21.3 ft in 6500 mm
Dimensions
Width to Outside of Tracks 11.6 ft in 3540 mm
Height to Top of Cab 10.6 ft in 3225 mm
Ground Clearance 1.7 ft in 530 mm
Counterweight Clearance 4 ft in 1210 mm
Tail Swing Radius 11.7 ft in 3560 mm
Length of Track on Ground 13.9 ft in 4240 mm
Volvo EC380D L EC380DL Excavator Service Repair Manual is written step by step in details, so you become very easy to repair by yourself. It can save your expenses.
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
Volvo Ec380d L Ec380dl Excavator Service Repair Manual
